- Size: 1460*860*1910mm
- Place of Origin: Shandong
- Brand Name: ROADWAY
- Model Number: RWYL35 / RWYL35C
- Weight: 880.000 kg
RWYL35/35C walk behind hydraulic road roller (fully hydraulic)
The machine is mainly used to compress on the asphalt, sand soil and gravel.
It is also used to planish the lawn and playground.
Product characteristics
1. China top brand diesel engine, or Honda gasoline engine.
2. Imported Sauer heavy-duty variable plunger pump drives the machine step-less speed walking.
3. Double American brand cycloid hydraulic motors drive the machine walking.
4. Imported brand motor drives the steel drum vibrating, button controlled
5. Forward/reverse running, left/right steering and vibrating all controlled by the integrated control lever.
6. Stainless water-praying pipe.
7. Plastic water tank, free from corrosion and convenient for the water-spraying.
8. Dead-man safety control.
- Size: 1460*860*1910mm
- Place of Origin: Shandong
- Brand Name: ROADWAY
- Model Number: RWYL35 / RWYL35C
- Weight: 880.000 kg
Technical Parameter of RWYL35/ RWYL35C
Type | RWYL35 | RWYL35C | |
Run | |||
Speed | 0—3.6km/h (Forward and back) | ||
Turning angle | ±15° | ||
Climbing capacity in theory | 25% | ||
Compaction | |||
Static load forward/back | 60/64N/cm | 62/65N/cm | |
Nominal amplitude | 0.5mm | ||
Vibration frequency | 60Hz | ||
Exciting force | 20kN | ||
Water tank volume | 50L | ||
Working | |||
Drive | Variable plunger pump ,constant displacement hydraulic motor | ||
Vibration | Hydraulic vibrating | ||
Turning | Hydraulic steering | ||
Engine | |||
Model | HONDA, GX390 | 186F | |
Type | Gasoline engine, air cooled, 4stroke, OHV, single cylinder | Diesel engine, air cooled, 4stroke, vertical type, single cylinder | |
Power | 13.0hp/3600rpm | 8.0hp/3600rpm | |
Fuel tank volume | 6.5L | 5.5L | |
Lubricant L | 1.1L | 1.65L | |
Fuel consumption | 313g/kWh | 280g/kWh | |
Dimension | |||
Width of steel wheel | 680mm | ||
Diameter of steel wheel | 355mm | ||
Tread | 650mm | ||
Total length(keep handrail level) | 2440mm | ||
Total width | 755mm | ||
Total height(keep handrail upright) | 1800mm | ||
Packing size | 1460x860x1910mm | ||
Weight | |||
Working weight | 860kg | 880kg |
